YIHUA 3005D-II Dc Power Supply Dual-Channel 30V 5A x 2 ลดล้างสต๊อกครับ มี 3 ตัว

ลดล้างสต๊อกครับ มีแค่ 3 ตัว

PRODUCT SPECIFICATIONS:
- Model: YH-3005D-II
- Compact Design
- SMT Construction
- Dual LED 4 Digital Tube Display
- Independent Operations Mode(2X 30V 5A)/ Series Tracking Mode（60V 5A）/ Parallel Tracking Mode（30V 10A）
A 2.5V/3.3V/5V Fixed Output Function
- High Stabilized Output Voltage
- Current-limiting Buck
- Short Circuit Protection
- Over Loading and Voltage Protection
- Overheating Protection
- Low noise
- CE Certification

Channel II Independent Mode
Output Voltage : continuously adjustable between 0-30V
Output Current : continuously adjustable between 0-5

Power Effect:
CV≤0.01%+1mV   CC≤0.2%+1mA

Load Effect:
CV≤0.01%+5mV (I≤3A)    CC≤0.2%+5mA (I≤3A)
CV≤0.01%+7mV (I>3A)     CC≤0.2%+10mA (I>3A)

Ripple Noise (5Hz-1MHz) :
CV≤0.5mVrms (I≤3A)  CC≤3mArms (I≤3A)
CV≤1mVrms (I>3A)    CC≤5mArms (I>3A)

Voltage Accuracy:  ±0.5%rdg+2 characters
Voltage Accuracy: ±0.5%rdg+2 characters
Display Resolution: ±0.5%rdg+2 characters

Channel III Output Characteristics
Rated Output Voltage : 2.5V/3.3V/5V±0.1
Rated Output Current : 3A
Power Effect: ≤1mV
Load Effect: ≤10mV
Ripple Noise(5Hz-1MHz): ≤1mVrms

Tracking Characteristics
Characteristics Operating in Series
Power Effect: ≤1mV
Load Effect: ≤30mV
Ripple Noise(5Hz-1MHz): ≤1mVrms

Characteristics Operating in Parallel
Power Effect: ≤1mV
Load Effect: ≤20mV
Ripple Noise(5Hz-1MHz): CV≤0.5mVrms (I≤6A)  CV≤1mVrms (I>6A)

Safety Requirements:
HV Test: Leakage current ≤1mA (Test condition: input to ground of 1700VAC/2S)
Insulation Test: Insulation resistance ≥100MΩ (Test condition: input to ground of 500VDC/5S)
