Specifications |
Temperature Range |
-30°C to 350°C (-22°F to 662°F) |
Accuracy (Calibration geometry with ambient temperature 23°C ±2°C) |
≥ 0°C |
±2.0°C or ±2.0% of reading, whichever is greater |
≥ -10°C to <0°C |
±2.0°C |
< -10°C |
±3.0°C |
≥ 32°F |
±4.0°F or ±2.0% of reading, whichever is greater |
≥ 14°F to <32°F |
±4.0°F |
< 14°F |
±6.0°F |
Response Time (95%) |
< 500 ms (95% of reading) |
Spectral Response |
8 mm to 14 mm |
Emissivity |
0.10 to 1.00 |
Distance to Spot Ratio |
8:1 (calculated at 90% energy) |
Display Resolution |
0.1°C (0.2°F) |
Repeatability (% of reading) |
±1.0% of reading or ±1.0°C (±2.0°F), whichever is greater |
Power |
1 AA IEC LR06 Battery |
Battery Life |
12 hours with laser and backlight on |
Weight |
220 g (7.76 oz) |
Size |
156 x 80 x 50 mm (6.14 x 3.15 x 2 in) |
Operating Temperature |
0°C to 50°C (32°F to 122°F) |
Storage Temperature |
-20°C to +60°C (-4°F to 140°F), (without battery) |
Operating Humidity |
10% to 90% RH non-condensing @ 30°C (86°F) |
Operating Altitude |
2000 meters above mean sea level |
Storage Altitude |
12,000 meters above mean sea level |
Drop Test |
1 m |
Ingress Protection Rating |
IP40 per IEC 60529 |
Vibration and Shock |
IEC 68-2-6 2.5 g, 10 to 200 Hz, IEC 68-2-27, 50 g, 11 ms |
Compliance |
EN/IEC 61010-1 |
Laser Safety |
FDA and EN 60825-1 Class II |
Electromagnetic Compatibility |
61326-1 EN 61326-2 |
